EG4-WallMount Indoor Battery | 48V 314Ah | 16kWh | UL9540A | Self-Heating

The EG4-WallMount Indoor Battery (48V 314Ah, 16kWh) is a high-capacity, indoor-rated energy storage solution engineered for residential and light commercial solar and backup power systems. Built with Lithium Iron Phosphate (LFP) chemistry, this battery delivers exceptional safety, long cycle life, and reliable performance for daily energy storage and backup applications.

Designed for modern energy systems, the EG4 WallMount Battery features an integrated Battery Management System (BMS), self-heating capability for cold environments, and support for large parallel configurations. With high efficiency, robust protection features, and flexible inverter compatibility, it is an ideal solution for homeowners seeking dependable, scalable indoor energy storage.

EG4-WallMount Indoor Battery | 48V 314Ah | 16kWh | UL9540A | Self-Heating Features

High-Capacity 16kWh Energy Storage - Provides 16kWh nominal energy with 12.86kWh usable energy (80% DoD recommended) for dependable daily use and backup power.

Lithium Iron Phosphate (LFP) Chemistry - Offers enhanced safety, thermal stability, and long cycle life compared to traditional lithium-ion batteries.

Self-Heating Battery Technology - Integrated battery heater enables reliable charging and operation in cold environments, automatically activating when internal temperatures drop.

Powerful Charge & Discharge Performance - Supports up to 10.2kW continuous charge/discharge power with 12.8kW peak power (3 seconds) for handling demanding loads.

Integrated Smart Battery Management System (BMS) - Built-in BMS with active balancing protects against over/under voltage, over-current, short circuit, and temperature extremes.

High Parallel Scalability - Supports up to 32 batteries in parallel, making it suitable for larger residential or light commercial energy storage systems.

EG4-WallMount Indoor Battery | 48V 314Ah | 16kWh | UL9540A | Self-Heating Applications

Residential solar energy storage – Store excess solar power for nighttime use
Home backup power – Maintain power during grid outages
Hybrid inverter systems – Integrates with compatible 48V inverter platforms
Load shifting – Reduce peak energy costs by using stored power
Cold-climate installations – Self-heating design supports reliable winter operation

What's Included

Everything you need is included with your product.

(1) Mounting Bracket
(1) X Bracket
(6) Expansion Bolt

(2) Red & Black Battery to Inverter Power Cables (3.3 FT)
(1) Battery to Inverter Comm Cable (5 FT)
(1) User Manual

Warranty

10-year warranty

EG4-WallMount Indoor Battery | 48V 314Ah | 16kWh | UL9540A | Self-Heating Specifications

Parameter	Specification
Product Type	LFP Battery
Battery Type	Lithium Iron Phosphate (LFP
Model Number	WM-48-314-IN-XX / WM48314INXX (XX is a number between 00 – 99

Electrical Characteristics

Parameter	Specification
Nominal Energy Capacity	16 kWh
Usable Energy (DOD%)	12.86 kWh (80% recommended)
Recommended Voltage Range	47.5 – 57.6 VDC
Nominal Voltage	51.2 VDC
Capacity	314 Ah
Charging Voltage Range	56 – 57 VDC
Discharging Cut-Off Voltage	47.5 VDC
Max Continuous / Recommended Charge Current	157A / 157A
Max Continuous / Recommended Discharge Current	200A / 157A
Continuous Charge / Discharge Power	8 / 10.2 kW
Recommended Charging / Discharging Rate	0.5C
Short Circuit Current	1700A, 15 ms delay
Peak Power	12.8 kW (3 sec)
Round-Trip Efficiency	95%
Max Parallel Units	32
Protection Features	Over/Under Voltage, Over-Current, Short Circuit, High/Low Temp
Battery Management System (BMS)	Integrated, Active Balancing
Communication Protocols	RS485, CAN
Battery Breaker	250A

Battery Heater Specifications

Parameter	Specification	Condition
Voltage	56V	-
Power Consumption	448W	-
Internal Battery Temperature	≤32°F (0°C) / ≥37°F (3°C)	Heat On / Heat Off

Environmental Specifications

Parameter	Specification
Storage Temperature Range*	−4 – 131°F (−20 – 55°C)
Humidity Range	5% – 95% RH (non-condensing)
Altitude	9843 ft (<3000 m)
Cooling Method	Natural Convection
Dimensions (H × W × D)	34.1 in × 18.1 in × 9.6 in (865 mm × 460 mm × 245 mm)
Operating Temperature Range	Charge: 32 – 122°F (0 – 50°C) \| Discharging: −4 – 131°F (−20 – 55°C)

Mechanical Specifications

Parameter	Specification
Weight	293.2 lbs (133 kg)
Enclosure Rating	IP20
Enclosure Rating	Floor mount / wall attached
Display / Indicators	LED Status
Connector Type	Degson quick connector / screw terminals

Certifications & Compliance

Parameter	Specification
UL 1973	Yes
UL 9540	See https://eg4electronics.com/ for supported UL 9540 configurations
UL 9540A	Cell, Module (Pending), Unit Level (Pending)
UN 38.3	Yes

Warranty & Lifecycle

Parameter	Specification
Cycle Life (70% EOL Capacity)*	10,000 cycles @ 0.5C, 25°C, 80% DOD
Design Life	15 years
Warranty	10 years or 10,000 cycles
Lifetime Production**	122.2 MWh
Application Type	Residential / Commercial / Off-Grid / Backup

Frequently-Asked Questions

Is this battery compatible with 48V inverter systems?

Yes. The EG4 WallMount Battery is designed for 48V systems and supports RS485 and CAN communication for compatible inverters.

Can multiple batteries be connected together?

Yes. Up to 32 units can be connected in parallel, allowing significant system expansion.

Does this battery work in cold climates?

Yes. The integrated self-heating system allows the battery to operate and charge reliably in cold temperatures.

Is this battery suitable for indoor installation?

Yes. This model is designed specifically for indoor wall-mounted installation.
