BLUETTI Epad Central Control Screen

The BLUETTI Epad Central Control Screen is an intelligent monitoring and control interface designed to simplify power management for BLUETTI energy storage and backup systems. Built for users who want centralized visibility and easy system control, the Epad provides real-time performance data, operational settings, and streamlined access to key system functions. Whether used in home backup installations, off-grid power setups, or mobile energy systems, the Epad enhances user experience through convenient, centralized control.

BLUETTI Epad Central Control Screen Features

Centralized System Monitoring - Provides real-time visibility into power usage, battery status, and system performance.

User-Friendly Touchscreen Interface - Intuitive display design makes it easy to view data and adjust settings quickly.

Designed for BLUETTI Ecosystem Integration - Built specifically for compatible BLUETTI power systems, ensuring seamless connectivity.

Improved Energy Management - Helps optimize system operation, making backup and off-grid setups easier to manage.

Ideal for Home and Off-Grid Installations - Perfect for stationary power systems, providing centralized control in one convenient screen.

BLUETTI Epad Central Control Screen Applications

• Home Backup Power Systems – Central monitoring for household energy storage

• Off-Grid Solar Installations – Manage solar charging and battery performance

• Energy Storage Control Centers – Streamlined interface for system operation

• Mobile Power Setups – Useful for RV or remote power management

• System Expansion & Monitoring – Ideal for larger multi-component BLUETTI setups

What's Included

Everything you need is included with your product.

BLUETTI Epad Central Control Screen

User Manual

BLUETTI Epad Central Control Screen Specifications

Specification	Details
Model	Epad
Weight	Approx. 0.67 kg/1.48 lbs (without brackets)
Dimensions (L × W × H)	247 × 158 × 34.2 mm/9.72 × 6.22 × 1.35 in (without brackets)
Operating Temperature	-10°C to 55°C/14°F to 131°F
Storage Temperature	-20°C to 55°C/-4°F to 131°F
Protection Rating	IP20
Power Consumption	Approx. 6 W (screen on) / 2.5 W (screen off)
USB-C Input	4.5 V to 5.5 VDC, 3 A Max.

Connectivity

Specification	Details
CAN Port × 2	Non-isolated RJ45, for RV5 or Epanel
Ethernet	10/100 Mbps, auto-negotiation
Wi-Fi (Built-in Antenna) Frequency	2,412 MHz to 2,472 MHz
Transmit Power	20 dBm Max.
Modulation	DBPSK, DQPSK, CCK, BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
Bluetooth 5.2 (Built-in Antenna) Frequency	2,402 MHz to 2,480 MHz
Transmit Power	10 dBm Max.
Modulation	GFSK
microSD Slot	Supports SDHC cards (32 GB Max.)
USB-A × 2	5 V/1.5 A total, supports up to 32 GB USB flash drives per port

External Devices

Specification	Details
Temperature Sensor Range	-20°C to 70°C (±2°C)/-4°F to 158°F (±3.6°F)
Liquid Level Sensor	Range: 0% to 100% (±2%); Supported Resistance: EU: 0–180 Ω \| US: 240–30 Ω
No. of Digital Inputs	2
Dry Contacts Outputs	2 relays (NO, COM, NC); Load Capacity: 30 V DC/3 A \| 125 V AC/3 A

Display

Specification	Details
Type	Color LCD
Size	10.1"
Resolution	1280 × 800
Touchscreen	Capacitive

Other Features

Specification	Details
Temperature Measurement	-20°C to 70°C (±2°C)/-4°F to 158°F (±3.6°F)
Humidity Measurement	0% to 100% (±2%)
Buzzer	Built-in
RTC (Real-Time Clock)	Built-in
Ambient Light Sensor	Built-in for auto screen brightness adjustment

Frequently-Asked Questions

What does the BLUETTI Epad do?

The Epad is a centralized control screen that allows users to monitor and manage compatible BLUETTI energy storage systems from one interface.

Is the Epad required to operate a BLUETTI system?

No. The Epad is an optional accessory designed to enhance convenience and provide easier monitoring.

Can the Epad be used in off-grid systems?

Yes. It is especially useful for off-grid solar and battery installations where centralized control is valuable.

Is professional installation recommended?

For permanent home or system-integrated installations, professional setup is recommended.

Manual

• BLUETTI Epad Central Control Screen Manual
