Liniotech 3600W Off-Grid Inverter | 4000W PV Input | 3600W Output | 300V VOC Input | 48V 120 Single Phase | All-In-One Solar Inverter

Liniotech 3600W Off-Grid Inverter | 4000W PV Input | 3600W Output | 300V VOC Input | 48V 120 Single Phase | All-In-One Solar Inverter

BY: Liniotech | SKU: LNT3600-48 Availability: In Stock
$699.00

Notify me when back in stock

Found a Better Price?

Share it with us now and we will beat it. Get the best deal online - Guaranteed!

Call/Text Us: 877-556-3347
Live Chat With an Expert

  • Authorized Liniotech Dealer

    Full manufacturer warranty included

  • Free Shipping + No Sales Tax (Most States)

    More savings on every purchase

  • Easy 30-Day Returns & Price Beat Guarantee

    Risk-free shopping + best price guaranteed

  • Lifetime Expert Support

    Dedicated help whenever you need it

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Liniotech 3600W Off-Grid Inverter | 4000W PV Input | 3600W Output | 300V VOC Input | 48V 120 Single Phase | All-In-One Solar Inverter

The Liniotech 3600W Off-Grid Inverter is a premium all-in-one hybrid solar inverter designed for efficient power conversion in residential, commercial, and off-grid energy systems. With a 3600W output capacity, 4000W PV input, and advanced MPPT solar charge controller, it ensures maximum power efficiency and stable electricity for your home or business. Built with robust safety protections, smart monitoring, and flexible battery compatibility, this inverter is a reliable solution for both backup power and complete off-grid living.

Placeholder Image

Liniotech 3600W Off-Grid Inverter Features

Pure Sine Wave Output (120V Single Phase)

Provides clean, reliable AC power for sensitive appliances and electronics.

Built-in 4000W MPPT Solar Charge Controller

Optimizes solar efficiency by intelligently tracking the maximum power point.

Wide PV Input Voltage Range (Max 300V DC)

Compatible with a wide variety of solar panel configurations.

Supports Multiple Battery Types

Works with 48V lithium, AGM, GEL, and flooded lead-acid batteries.

Fast 80A Charging Current

Recharges batteries quickly, reaching full charge in as little as 2 hours (with 5.12kWh battery).

Battery-Free Operation

Can operate directly from solar panels when battery is not present.

Smart Monitoring System

Real-time monitoring via WiFi, RS485, USB, and GPRS, accessible through mobile apps.

Stackable Design

Parallel up to 6 units to expand power capacity to 21.6kW for large systems.

One-Key Factory Reset & Anti-Dust Kit

Simplifies system reset and enhances durability in dusty environments.

Placeholder Image

Liniotech 3600W Off-Grid Inverter Applications

  • Residential solar backup systems – power homes during outages
  • Off-grid cabins & remote living – reliable energy where grid access is limited
  • Mobile solar setups (RVs, vans) – compact power conversion for travel
  • Workshops & small businesses – stable energy for tools and equipment
Placeholder Image

What's Included

Everything you need is included with your product.

  • Liniotech 3600W Off-Grid Inverter | 4000W PV Input | 3600W Output | 300V VOC Input | 48V 120 Single Phase | All-In-One Solar Inverter
  • User Manual

Warranty

  • 3-Year Manufacturer Warranty

Liniotech 6500W Off-Grid Inverter Specifications

Parallel Mode (Function Reserved)

Specifications Details
Allow Quantity 1–6

What is Lorem Ipsum?

Specifications Details
Nominal Input Voltage 120V ±5%
Input Voltage Range 90Vac–140Vac ±2%
Frequency 50Hz/60Hz (Auto Detection)
Frequency Range 47 ±0.3Hz – 55 ±0.3Hz (50Hz) | 57 ±0.3Hz – 65 ±0.3Hz (60Hz);
Max. Efficiency ≥95%
Conversion Time (Bypass & Inverter) 10ms (Typical)
Max. Bypass Phase Overload Current 40A

Inverter Mode

Specifications Details
Output Voltage waveform Pure sine wave
Nominal Output Power (VA/W) 3600 VA / 3600 W
Nominal Output Voltage (VAC) 120 Vac
Output Frequency Range (Hz) 50 Hz ± 0.3 Hz / 60 Hz ± 0.3 Hz
Power factor 1
Max efficiency ≥ 91%
Overload protection (102% < load < 125%) ±10% → Report error and turn off output after 5 minutes; (125% < load < 150%) ±10% → Report error and turn off output after 10 seconds' Load > 150% ±5% → Report error and turn off output after 5 seconds
Peak power 72,000 VA
Loaded motor capability 2 HP
Nominal battery input 48 V (min start 44 V)
Battery voltage range 40.0 Vdc ~ 60 Vdc ±0.5 Vdc
Save-power mode Loads ≤ 25 W enter power-saving mode

Mains Charge

Specifications Details
Battery type Lead-acid or lithium
Max charge current (configurable) 40 A
Charge voltage range 40–60 Vdc

Solar Charge

Specifications Details
Max PV open-circuit voltage 300 Vdc
PV operating range 80–300 Vdc
MPPT voltage range 90–250 Vdc
Battery voltage range 40–64 Vdc
Max PV input power / current 4,000W/ 22A
Charge current range (Configurable.) 0–80 A

Max. Hybrid Charge Current

Specifications Details
Max hybrid charge current (config.) 0–150 A

Certification

Specifications Details
Safety Certification CECIEC62109-1.2
EMC Certification level EN61000,C2
Operating Temperature Range −15 °C to 55 °C
Storage Temperature Range −25 °C to 60 °C
Humidity Range 5% to 95% (three-anti paint protection)
Noise ≤ 60 dB
Cooling Forced air cooling, dual intelligent speed-regulated fans
Communicate USB / RS485 / Wi-Fi (GPRS) / dry-contact control
Dimensions (LxWxD mm) 415 × 280 × 100 mm
Weight 7.8 kg

Frequently-Asked Questions

Can I expand the inverter system?

Yes, you can parallel up to 6 units for a maximum output of 21.6kW.

Does it work without a battery?

Yes, it can operate directly from solar panels even if no battery is connected.

What types of batteries are supported?

It supports Lithium (LiFePO₄), AGM, GEL, and Flooded lead-acid batteries.
