Liniotech 6500W Off-Grid Inverter | 9000W PV Input | 6500W Output | 300V VOC Input | 48V 120 Single Phase | All-In-One Solar Inverter

The Liniotech 6500W Off-Grid Inverter is an all-in-one solar inverter built for reliable energy independence in homes, cabins, RVs, and workshops. With 9,000W PV input, 6.5kW continuous AC output, and pure sine wave technology, it delivers stable power for sensitive electronics and heavy loads. Featuring multiple MPPTs, stackable design (up to 6 units), and compatibility with Lithium, AGM, GEL, and Lead-acid batteries, it’s a versatile and efficient choice for off-grid and hybrid solar energy systems.

Liniotech 6500W Off-Grid Inverter Features

High Power Output

Delivers 6,500W continuous AC output (120V ±5%) with 95% efficiency for reliable off-grid power.

Large Solar Input Capacity

Supports up to 9,000W PV input (4500W × 2 MPPTs) with 300V max VOC for flexible solar array designs.

Smart Battery Management

Works with 48V battery systems and supports up to 150A adjustable charging current.

Parallel Expansion

Stack up to 6 units in parallel for larger system capacity.

Universal Battery Compatibility

Compatible with LiFePO4, AGM, GEL, and Lead-acid batteries.

Robust Protection

Built-in protections include overload, overvoltage, short circuit, and overtemperature safeguards.

Compact & Efficient

Lightweight design with forced air cooling and dual intelligent speed-regulating fans ensures reliability.

Liniotech 6500W Off-Grid Inverter Applications

Off-grid homes – run household appliances with stable solar power
Cabins – perfect for remote living with independent energy
RVs & mobile power setups – reliable inverter for travel and mobility
Workshops – supports tools and equipment with high surge capacity

What's Included

Everything you need is included with your product.

Liniotech 6500W Off-Grid Inverter | 9000W PV Input | 6500W Output | 300V VOC Input | 48V 120 Single Phase | All-In-One Solar Inverter

User Manual

Warranty

3-Year Manufacturer Warranty

Liniotech 6500W Off-Grid Inverter Specifications

Parallel Mode (Function Reserved)

Specifications	Details
Allow Quantity	1–6

What is Lorem Ipsum?

Specifications	Details
Nominal Input Voltage	120V ±5%
Input Voltage Range	90Vac–140Vac ±2%
Frequency	50Hz/60Hz (Auto Detection)
Frequency Range	47 ±0.3Hz – 55 ±0.3Hz (50Hz) \| 57 ±0.3Hz – 65 ±0.3Hz (60Hz);
Max. Efficiency	≥95%
Conversion Time (Bypass & Inverter)	10ms (Typical)
Max. Bypass Phase Overload Current	63A

Inverter Mode

Specifications	Details
Output Voltage waveform	Pure sine wave
Nominal Output Power (VA/W)	6500 VA / 6500 W
Nominal Output Voltage (VAC)	120 Vac
Output Frequency Range (Hz)	50 Hz ± 0.3 Hz / 60 Hz ± 0.3 Hz
Power factor	1
Max efficiency	≥ 91%
Overload protection	(102% < load < 125%) ±10% → Report error and turn off output after 5 minutes; (125% < load < 150%) ±10% → Report error and turn off output after 10 seconds' Load > 150% ±5% → Report error and turn off output after 5 seconds
Peak power	12,000 VA
Loaded motor capability	5 HP
Nominal battery input	48 V (min start 44 V)
Battery voltage range	40.0 Vdc ~ 60 Vdc ±0.6 Vdc (Undervoltage alarm/shutdown voltage, overvoltage alarm/overvoltage recovery — settable on LCD screen)
Save-power mode	Loads ≤ 25 W enter power-saving mode

Mains Charge

Specifications	Details
Battery type	Lead-acid or lithium
Max charge current (configurable)	120 A
Charge voltage range	40–60 Vdc

Solar Charge

Specifications	Details
Max PV open-circuit voltage	300 Vdc
PV operating range	80–300 Vdc
MPPT voltage range	90–250 Vdc
Battery voltage range	40–64 Vdc
Max PV input power / current	4,500Wx2/ 22 A × 2
Charge current range (Configurable.)	0–150 A

Max. Hybrid Charge Current

Specifications	Details
Max hybrid charge current (config.)	0–150 A

Certification

Specifications	Details
Safety Certification	CECIEC62109-1.2
EMC Certification level	EN61000,C2
Operating Temperature Range	−15 °C to 55 °C
Storage Temperature Range	−25 °C to 60 °C
Humidity Range	5% to 95% (three-anti paint protection)
Noise	≤ 60 dB
Cooling	Forced air cooling, dual intelligent speed-regulated fans
Communicate	USB / RS485 / Wi-Fi (GPRS) / dry-contact control
Dimensions (LxWxD mm)	550 × 365 × 130 mm
Weight	20kg

Frequently-Asked Questions

Can this inverter be expanded for larger systems?

Yes, up to 6 units can be stacked in parallel for expanded capacity.

What types of batteries are supported?

It works with Lithium (LiFePO4), AGM, GEL, and Lead-acid batteries.

Does it output clean power for electronics?

Yes, it provides pure sine wave output, making it safe for sensitive devices.
