Mango Power E Expansion Battery Solar Generator Expansion Batteries Mango Power

Mango Power E Expansion Battery

Name: Mango Power E Expansion Battery
Brand: Mango Power
SKU: MPE02US1N001
Price: 1199.0 USD
Availability: InStock

BY: Mango Power

SKU: MPE02US1N001

| Availability: In stock

$2,999.00

$1,199.00

You Save: $1,800.00

Found A Better Price?

Share it with us now and we will beat it. Get the best deal online, guaranteed!

Live Chat With an Expert

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Order within

to get it by the earliest date.

Authorized Mango Power Dealer

Free & Fast Shipping From US Warehouses

Easy 30-Day Returns & Price Beat Guarantee

Lifetime Expert Support

Mango Power E Expansion Battery

The Mango Power E Expansion Battery is a mobile energy storage battery designed to expand compatible Mango Power E systems. It provides 3533Wh battery capacity, uses CATL LFP cell chemistry, and includes built-in battery management protections. It connects through the E+ Connection Cable and supports charging by AC, wall outlet, or AC adapter when connected to a Mango Power E unit.

Mango Power Solar Generator Kit Features

3533Wh Expansion Battery Capacity - Adds 3533Wh of battery capacity to a compatible Mango Power E setup.

CATL LFP Cell Chemistry - Built with CATL LFP cells for mobile energy storage use.

6000-Cycle Life Span - Rated for 6000 cycles to 70% capacity at 25°C ± 0.5°C / 0.5C / -0.5C.

Built-In Battery Management System - Includes protection against over-voltage, overload, over-temperature, short circuit, low temperature, and low voltage.

Up to 1.1C Max Charging Rate - Supports a maximum charging rate of up to 1.1C.

Multiple Charging Methods - Charging method includes AC, wall outlet, and AC adapter.

AC Charging Support - Supports max 3000W AC charging when connected to a Mango Power E through an AC adapter.

Compact Mobile Energy Storage Design - Measures 17.8 x 13.6 x 12.5 in and weighs 73.1 lbs / 33.18 kg.

Mango Power E Expansion Battery Applications

Mango Power E Expansion – Adds 3533Wh of battery capacity to a compatible Mango Power E system.
Mobile Energy Storage – Designed as a mobile energy storage battery for supported Mango Power setups.
Backup Power Extension – Helps extend available stored energy when paired with the Mango Power E.
AC Charging Support – Supports AC charging when connected to Mango Power E through an AC adapter.
Protected Battery Storage – Uses built-in battery management protections for supported charging and storage use.

What's Included

Everything you need is included with your product.

1 x Mango Power E Battery
1 x E+ Connection Cable

1 x Quick Guide
1 x Warranty Card

Mango Power E Expansion Battery Specifications

General

Specification	Details
Net Weight	73.1lbs (33.18kg)
Size	17.8x13.6x12.5 inches (452x345x318mm)
Working Temperature	Charging: -10°C~45°C(14℉~113℉) \| Discharging: -20°C~45°C(-4℉~113℉)
Warranty	5 years
Certifications	Meets US and International Safety and EMI Standards
IP level	IP21

Battery

Specification	Details
Battery Capacity	3533Wh
Cell Chemistry	World’s best CATL LFP
Life Span	Capacity Retention >70% after 6000 cycles （@25℃, +0.5C/-0.5C）
Battery Management Systems	Over Voltage Protection, Overload Protection, Over Temperature Protection, Short Circuit Protection, Low Temperature Protection, Low Voltage Protection, Overcurrent Protection
Max charging rate	Up to 1.1C

Input

Specification	Details
Charging Method	AC Wall Outlet, AC Adapter
AC Charging	Max 3000W(by connected to MANGO POWER E)/AC Adapter

Output

Specification	Details
Output Ports	3
USB-A	1 x QC 3.0 24W
USB-C	1 x PD 100W
Car Power Output	12V/10A

Frequently-Asked Questions

What is the capacity of the Mango Power E Expansion Battery?

The Mango Power E Expansion Battery has a 3533Wh battery capacity.

What battery chemistry does it use?

It uses CATL LFP cell chemistry.

What is the cycle life?

The battery is rated for 6000 cycles to 70% capacity at 25°C ± 0.5°C / 0.5C / -0.5C.

What charging methods are supported?

The charging methods listed are AC, wall outlet, and AC adapter.

What is the maximum AC charging power?

The battery supports max 3000W AC charging when connected to Mango Power E through an AC adapter.

Does it include battery protection features?

Yes. It includes battery management protections such as over-voltage, overload, over-temperature, short circuit, low temperature, low voltage, and overcurrent protection.

What is the IP level?

The IP level is IP21.

How much does the battery weigh?

The Mango Power E Expansion Battery weighs 73.1 lbs / 33.18 kg.

What comes in the box?

The box includes the Mango Power E Battery, E+ Connection Cable, Quick Start Guide, Warranty Card, and QC PASS Certificate.

Manual

Mango Power E Expansion Battery User Manual
