Mango Power Solar Generator Kit Max

Name: Mango Power Solar Generator Kit Max
Brand: Mango Power
SKU: MPE01US1N001+MPA05US1N005*4+MPA06US1N008
Price: 3199.0 USD
Availability: InStock

BY: Mango Power

SKU: MPE01US1N001+MPA05US1N005*4+MPA06US1N008

| Availability: In stock

$9,095.00

$3,199.00

You Save: $5,896.00

Product Highlights

Built for home backup, off-grid power, and RV travel
3,533 Wh capacity for extended backup and off-grid runtime
400 W solar output for larger off-grid energy systems
3,000 W output to run high-demand appliances and equipment

Found A Better Price?

Share it with us now and we will beat it. Get the best deal online, guaranteed!

Live Chat With an Expert

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Order within

to get it by the earliest date.

Authorized Mango Power Dealer

Free & Fast Shipping From US Warehouses

Easy 30-Day Returns & Price Beat Guarantee

Lifetime Expert Support

Mango Power Solar Generator Kit Max

The Mango Power Solar Generator Kit Max is a bundled solar generator setup that includes 1 Mango Power E Portable Power Station, 2 Mango Power 400W Ultra-Light Portable Solar Panels, and 1 Mango Power Solar Parallel Connection Cable. The Mango Power E provides 3533Wh capacity, 3000W total AC output, max 3000W AC charging input, and max 2000W solar charging input. The included 400W solar panels and solar parallel connection cable support a larger portable solar charging setup.

Mango Power Solar Generator Kit Max Features

Solar Generator Kit Max Setup - Includes 1 Mango Power E Portable Power Station, 2 Mango Power 400W Ultra-Light Portable Solar Panels, and 1 Mango Power Solar Parallel Connection Cable.

3533Wh Mango Power E Capacity - The Mango Power E provides 3533Wh capacity for backup power, portable power, and solar generator use.

3000W Total AC Output - The Mango Power E includes 4 x 20A AC outputs with 3000W total AC output.

Max 3000W AC Charging Input - Supports max 3000W AC charging input for charging from AC power.

Max 2000W Solar Charging Input - Supports max 2000W solar charging input with a 60V-150V solar charging input range.

Two 400W Ultra-Light Portable Solar Panels - The kit includes 2 Mango Power 400W Ultra-Light Portable Solar Panels, each with 400W max power output.

23% Solar Conversion Efficiency - Each 400W solar panel uses monocrystalline silicon cells with 23% conversion efficiency.

LFP Battery Chemistry - The Mango Power E uses LFP battery chemistry and is rated for 6000 cycles to 70% capacity.

Multiple Output Options - The Mango Power E includes AC output, USB-A output, USB-C output, car power output, DC5521 output, and a 30A AC RV port.

Mango Power Solar Generator Kit Max Applications

Solar Charging – Includes 2 x 400W Ultra-Light Portable Solar Panels for charging the Mango Power E with solar power.
Parallel Solar Panel Setup – Includes 1 Mango Power Solar Parallel Connection Cable for the included solar panel setup.
Home Backup Power – Uses the Mango Power E’s 3533Wh capacity and 3000W total AC output for compatible backup power needs.
Off-Grid Power Use – Combines a portable power station, solar panels, and parallel connection cable for off-grid energy setups.
AC Device Power – Supports compatible AC devices through the Mango Power E’s 4 x 20A AC outputs.
RV Power Use – Includes a 30A AC RV port for RV power applications.
Portable Device Charging – Supports USB-A, USB-C, car power, DC5521, and AC output options.
Generator Charging Support – Supports generator use based on the Mango Power E specifications.
EV Charging Input – Supports EV charging input with an adapter needed.

What's Included

Everything you need is included with your product.

1 x Mango Power E Portable Power Station
2 x Mango Power 400W Ultra-Light Portable Solar Panel
1 x Mango Power Solar Parallel Connection Cable

1 x Quick Guide
1 x Warranty Card

Mango Power E 240V Power Kit Pro Specifications

Specification	Details
Capacity	3533Wh
AC Output	4 x 20A, 3000W total
USB-A Output	6 x QC 3.0 24W
USB-C Output	1 x PD 65W + 1 x PD 100W
Car Power Output	12V / 10A
DC5521 Output	2x 12V / 5A
AC RV Port	30A
AC Charging Input	Max 3000W
Solar Charging Input	Max 2000W (60V-150V)
EV Charging Spot	Adapter needed
Generator	Support
Battery Chemistry	LFP
Cycle Span	6000 cycles to 70% capacity (@25 °C +0.5C/-0.5C)
Connection	Wi-Fi. Bluetooth
Net Weight	100.1 lbs / 45.4kg
Dimension	17.813.619.4 in / 45.234.549.4 cm

Mango Power 400W Ultra-Light Portable Solar Panel Specifications

Specification	Details
Model	Solar Move
Open-Circuit Voltage (Voc)	40.8V
Max Load Voltage (Vmp)	32.4V
Conversion efficiency	23%
Output Interface	MC4
Net Weight	7.8kg(17.2lbs)/±5 %
Folded Size	972 62065mm/±5 % 38.2724.412.56in/±5 %
Max Power (Pmax)	400W
Short-Circuit Current (Isc)	12.36A
Max Load Current (Imp)	11.7A
Cell Type	Monocrystalline silicon cell
Operating Temperature	-20°C～60°C(-4°F～140°F)
Unfolded Size	2460970mm/±5 96.8538.19in/±5 %
Warranty	18 Months

Video

Frequently-Asked Questions

What is included in the Mango Power Solar Generator Kit Max?

The kit includes 1 Mango Power E Portable Power Station, 2 Mango Power 400W Ultra-Light Portable Solar Panels, and 1 Mango Power Solar Parallel Connection Cable.

What is the capacity of the Mango Power E?

The Mango Power E has a 3533Wh capacity.

How much AC output does the Mango Power E provide?

The Mango Power E provides 4 x 20A AC outputs with 3000W total AC output.

What is the maximum AC charging input?

The Mango Power E supports max 3000W AC charging input.

What is the maximum solar charging input?

The Mango Power E supports max 2000W solar charging input with a 60V-150V input range.

How many solar panels are included?

This kit includes 2 Mango Power 400W Ultra-Light Portable Solar Panels.

What is the output of each solar panel?

Each Mango Power 400W Ultra-Light Portable Solar Panel has a 400W max power output.

What is the total rated solar panel output included in the kit?

The two included 400W solar panels provide a total rated solar panel output of 800W.

Does this kit include a solar parallel connection cable?

Yes. The kit includes 1 Mango Power Solar Parallel Connection Cable.

What is the solar panel conversion efficiency?

Each 400W solar panel has 23% conversion efficiency.

What battery chemistry does the Mango Power E use?

The Mango Power E uses LFP battery chemistry.

Does the Mango Power E support generator use?

Yes. The provided specifications show Generator: Support.

Does the Mango Power E support EV charging?

Yes. The specifications show EV Charging Spot: Adapter needed.

Does the Mango Power E support Wi-Fi and Bluetooth?

Yes. The Mango Power E supports Wi-Fi and Bluetooth connection.

What is the warranty for the solar panels?

The Mango Power 400W Ultra-Light Portable Solar Panel has an 18-month warranty.
