RUiXU RX-12K Split Phase Hybrid Inverter

Name: RUiXU RX-12K Split Phase Hybrid Inverter
Brand: Ruixu
SKU: RX-12K
Price: 3299.0 USD
Availability: InStock

BY: Ruixu

SKU: RX-12K

| Availability: In stock

$3,899.00

$3,299.00

You Save: $600.00

Found A Better Price?

Share it with us now and we will beat it. Get the best deal online, guaranteed!

Live Chat With an Expert

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Order within

to get it by the earliest date.

Authorized Ruixu Dealer

Free & Fast Shipping From US Warehouses

Easy 30-Day Returns & Price Beat Guarantee

Lifetime Expert Support

RUiXU RX-12K Split Phase Hybrid Inverter

The RUiXU RX-12K Split Phase Hybrid Inverter is a high-performance energy solution designed to seamlessly integrate solar power, battery storage, and grid energy. With split-phase capability, it delivers up to 11.4 kW of continuous AC power at 240V, making it ideal for residential and light commercial applications.

Featuring a four-channel Maximum Power Point Tracking (MPPT) system, the RX-12K supports up to 17.1 kW of photovoltaic (PV) input, maximizing solar energy harvesting. Its built-in 200A transfer relay enables whole-home backup power, ensuring reliability during outages.

Compatible with both lithium (LiFePO₄) and lead-acid batteries, this hybrid inverter offers flexible and scalable energy management. Designed for durability and easy installation, the IP65-rated enclosure makes it suitable for both indoor and outdoor use.

RUiXU RX-12K Split Phase Hybrid Inverter Features

AC Coupling Capability – Supports grid-tied and off-grid operation, allowing for quick retrofitting of existing solar systems.
All-in-One Hybrid Inverter – Operates off-grid, with grid assist, or in grid-tied mode, enabling users to sell power back to the grid.
Split-Phase High-Frequency Output – Supports 120/240V single unit operation or 120/208V service operation.
Generator-Compatible – Allows separate connections for grid and diesel generators, supporting energy storage from diesel generators.
High Output Power – Delivers up to 11.4 kW output, featuring an integrated 200A transfer relay for whole-home backup power.
MPPT Efficiency – Supports up to 4 MPPT channels, maximizing solar energy efficiency.
Uninterruptible Power Supply (UPS) – Provides seamless power transitions with a switching time ≤ 20ms.
Multiple Battery Compatibility – Supports 48V LiFePO₄ and lead-acid battery systems for customizable energy storage solutions.
Weather-Resistant Build – IP65-rated for indoor and outdoor installations.

RUiXU RX-12K Split Phase Hybrid Inverter Features

Whole-Home Backup Power – Provides emergency power during blackouts.
Solar Energy Storage – Works with off-grid or hybrid solar setups.
Commercial & Industrial Use – Ideal for businesses requiring reliable energy solutions.
RV & Marine Power Systems – Ensures steady, off-grid power for mobile and marine applications.
Remote & Off-Grid Living – A reliable solution for off-grid homes, cabins, and remote installations.

What's Included

Everything you need is included with your product.

(1) RUiXU RX-12K 12kW Hybrid Inverter
(1) 200cm CAT6 Communication Cable for battery connection

(1) WiFi Dongle for remote monitoring
(1) Operation Manual

Reliable Energy Management with a 10-Year Limited Warranty

The RUiXU RX-12K Split Phase Hybrid Inverter is an advanced, high-efficiency energy storage solution designed for resilient and independent power systems. With smart energy management, whole-home backup capability, and seamless grid integration, this inverter is an optimal choice for homeowners and businesses looking to maximize their solar energy investment.

RUiXU RX-12K Hybrid Inverter Specifications

Specification	Details
Nominal Voltage	380V
Max DC Voltage	600V
Battery Type	Lead-Acid or LiFePO₄
Battery Voltage Range	40V - 60V
Max AC Current @ 240V	52.3A
Operating Temperature Range	-40°F to 140°F
Dimensions (H x W x D)	30.7" x 18.5" x 10.2"
Weight	110 lbs
Shipping Restriction	Shipped with battery only, shipping fee if purchased alone, contact us for pricing.

Frequently-Asked Questions

What type of batteries can be used with the RX-12K Hybrid Inverter?

The RX-12K is compatible with both 48V Lithium Iron Phosphate (LiFePO₄) and Lead-Acid batteries, allowing flexible energy storage solutions.

Can the RX-12K Hybrid Inverter be used for whole-home backup?

Yes! With its 200A transfer relay, the RX-12K can automatically switch to battery power during grid outages, providing uninterrupted electricity for your home.

Is the RX-12K Hybrid Inverter suitable for off-grid installations?

Absolutely! It supports off-grid and hybrid solar systems, making it ideal for remote locations, cabins, and off-grid living.

Can this inverter connect to a diesel generator?

Yes, the RX-12K features dedicated generator input, allowing users to store excess power from diesel generators.

Does the inverter support solar panel expansion?

Yes! The RX-12K Hybrid Inverter supports up to 17.1kW of solar input, allowing for large-scale solar system setups.

How does the uninterruptible power supply (UPS) function work?

The RX-12K provides seamless power transition (≤ 20ms switching time), ensuring continuous operation for appliances and sensitive electronics.

Can I monitor and control the inverter remotely?

Yes! The RX-12K comes with a WiFi dongle and CAT6 communication cable, allowing real-time monitoring via mobile app or web portal.

Is the RX-12K inverter weather-resistant?

Yes, its IP65-rated enclosure makes it waterproof and dustproof, suitable for both indoor and outdoor installations.
