Sol-Ark 15K 120/240/208V 48V [All-In-One] Pre-Wired Hybrid Solar Inverter (EMP Hardened) | 10 Year Warranty

Name: Sol-Ark 15K 120/240/208V 48V [All-In-One] Pre-Wired Hybrid Solar Inverter (EMP Hardened) | 10 Year Warranty
Brand: Sol-Ark
SKU: 15K-2P-EMP
Price: 7600.0 USD
Availability: InStock

BY: Sol-Ark

SKU: 15K-2P-EMP

| Availability: In stock

$11,249.00

$7,600.00

You Save: $3,649.00

Found A Better Price?

Share it with us now and we will beat it. Get the best deal online, guaranteed!

Live Chat With an Expert

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Order within

to get it by the earliest date.

Authorized Sol-Ark Dealer

Free & Fast Shipping From US Warehouses

Easy 30-Day Returns & Price Beat Guarantee

Lifetime Expert Support

Sol-Ark 15K 120/240/208V 48V [All-In-One] Pre-Wired Hybrid Solar Inverter (EMP Hardened) | 10 Year Warranty

The Sol-Ark 15K 120/240/208V 48V Hybrid Solar Inverter is a high-capacity, all-in-one hybrid inverter designed for whole-home, commercial, and off-grid solar systems. This powerful inverter integrates solar, battery, and grid power with advanced intelligent energy management, making it one of the most efficient and reliable hybrid inverters available. Featuring a 10-year manufacturer warranty, built-in MPPT charge controllers, and grid-interactive technology, the Sol-Ark 15K provides seamless power switching and maximum energy savings.

Sol-Ark 15K 120/240/208V 48V Hybrid Solar Inverter (EMP Hardened) Features

All-In-One Hybrid Power System

Pre-wired hybrid inverter, integrating inverter, charger, and MPPT controllers.
Supports grid-tied, off-grid, and battery-backup operation.
Easy plug-and-play installation reduces labor costs and setup time.
200Amp automatic transfer switch built-in for seamless power transitions.

High Power Output & Efficiency

15,000W continuous output, supporting large residential and commercial loads.
Up to 19,500W PV input capacity with built-in MPPT charge controllers.
Compatible with 120V/240V split-phase and 208V three-phase power systems.

Smart Battery Backup & Management

Works with 48V battery banks, supporting LiFePO4, AGM, and lead-acid batteries.
Automatic switchover to backup mode for uninterrupted power during grid failures.
Customizable charge/discharge profiles for optimized battery lifespan and energy savings.

Scalability & Expandability

Parallel up to 12 inverters, achieving up to 180KW total output.
Compatible with multiple battery brands, allowing flexible system configurations.
Generator support for extended off-grid applications.

Advanced Smart Monitoring & Controls

Wi-Fi monitoring & mobile app support for real-time performance tracking.
Multiple communication interfaces (RS485, CAN, USB, Wi-Fi) for seamless integration with battery management systems (BMS) and smart grids.
Time-slot charging and discharging settings help optimize power use and energy savings.

Ultimate Safety & Protection Features

Built-in surge protection, overcurrent protection, and short circuit protection.
Anti-islanding protection for safe grid-tied interaction.
Smart cooling system to enhance durability and efficiency.

Sol-Ark 15K 120/240/208V 48V Hybrid Solar Inverter (EMP Hardened) Applications

Whole-Home Energy Backup – Provides seamless backup power during grid failures, keeping essential appliances running.

Off-Grid Solar Systems – Perfect for remote cabins, homes, and agricultural installations that require a fully self-sustaining power system.

Grid-Tied with Battery Backup – Reduce reliance on grid power with smart energy storage and net metering capabilities.

Commercial & Industrial Use – Supports large-scale solar arrays and provides high power capacity for businesses and factories.

RV & Mobile Solar Applications – A versatile and compact solution for off-grid and portable energy systems.

What's Included

Everything you need is included with your product.

Sol-Ark 15K 120/240/208V 48V Hybrid Solar Inverter (EMP Hardened)

User manual

SOL-ARK 15K-2P Hybrid Inverter (EMP Hardened) Specifications

Input Data (PV)

Specification	Details
Max. Allowed PV Power (STC)	19,500W
Rated MPPT Operating Voltage Range	175 - 425V
MPPT Voltage Range	150 - 500V
Startup Voltage	125V
Max. Input Voltage	500V
Max. Operating Input Current per MPPT	26A
Max. Short Circuit Current per MPPT	44A
No. of MPP Trackers	3
No. of PV Strings per MPPT	2
Max. AC Coupled Input	19,200W

Output Data (AC)

Specification	Details
Nominal AC Voltage	120/240V, 120/208V, 220V
Grid Frequency	50 / 60Hz
Real Power, max continuous	15,000W
Max. Output Current	62.5A
Real Power, max continuous (batteries only, no PV)	12,000W (50A @ 240V)
Peak Apparent Power (10s, off-grid)	24,000VA @ 240V
Peak Apparent Power (100ms, off-grid)	30,000VA @ 240V
Max Output Fault Current (5s)	94A with PV, 75A (batteries only)
Max Output Fault Current (100ms)	120A
Max. Grid Passthrough Current	200A
Power Factor Output Range	+/- 0.9 adjustable
Backup Transfer Time	5ms
CEC Efficiency	96.5%
Max Efficiency	97.5%
Design (DC to AC	Transformerless DC
Stackable	Up to 12 in parallel

Battery Input Data (DC)

Specification	Details
Battery Technologies	Lithium / Lead Acid
Nominal DC Voltage	48V
Operating Voltage Range	43 - 63V
Capacity	50 — 9900Ah
Max. Battery Charge / Discharge Current	275A
Charging Controller	3-Stage with Equalization
Grid to Battery Charging Efficiency	96.0%
External Battery Temperature Sensor (BTS)	Included
Automatic Generator Start (AGS)	2 Wire Start - Integrated
BMS Communication	CANBus & RS485 MODBUS

General Data

Specification	Details
Dimensions (H x W x D)	807 x 494 x 306 mm (31.8 x 19.4 x 12 in)
Weight	61.2 Kg / 135 lb.
Enclosure	IP65 / NEMA 3R
Ambient Temperature	-25~55°C, > 45°C Derating
Noise	< 30 dB @ 25°C (77°F)
Idle consumption	- No Load 90W
Communication and Monitoring	Wi-Fi & LAN Hardware Included
Standard Warranty	10 Years

Protection and Certifications

Specification	Details
Certifications and Listings	UL1741-2010/2018, IEEE1547a 2003/2014, FCC 15 Class B, UL1741SB, CA Rule 21, HECO Rule 14H
PV DC Disconnect Switch — NEC 240.15	Integrated
Ground Fault Detection — NEC 690.5	Integrated
PV Rapid Shutdown Control — NEC 690.12	Integrated
PV Arc Fault Detection — NEC 690.11	Integrated
PV Input Lightning Protection	Integrated
PV String Input Reverse Polarity Protection	Integrated
AC Output Breaker - 63A	Integrated
250A Battery Breaker / Disconnect	Integrated
Surge Protection	DC Type II / AC Type II

FAQs

Can the Sol-Ark 15K power my entire home?

Yes, the Sol-Ark 15K can handle whole-home power requirements, ensuring uninterrupted operation for HVAC systems, large appliances, and heavy electrical loads.

Does this inverter require batteries to function?

No, it can operate as a grid-tied inverter without batteries, allowing direct solar-to-grid energy usage.

How quickly does the inverter switch to battery power during outages?

The Sol-Ark 15K features a <10ms UPS switchover, ensuring continuous power without disruptions.

Is remote monitoring available?

Yes, the built-in Wi-Fi module allows for real-time system monitoring and remote adjustments via the Sol-Ark mobile app.

Can I expand my system with additional inverters?

Yes, the Sol-Ark 15K supports parallel operation with up to 12 units, allowing a total system capacity of 180KW.
