Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter + PowerMax 51.2V 314AH Outdoor Energy Storage Battery

Name: Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter + PowerMax 51.2V 314AH Outdoor Energy Storage Battery
Brand: SunGoldPower
SKU: SGN-11K15PRO+PowerMax314Outdoor-1
Price: 6212.5 USD
Availability: InStock

BY: SunGoldPower

SKU: SGN-11K15PRO+PowerMax 314 Outdoor-1

| Availability: In stock

$6,212.50

Inverter:

Battery:

Quantity

Product Highlights

Rugged power delivery for demanding loads and daily use
Built for home backup and off-grid power
16,070 Wh capacity for extended backup and off-grid runtime
11,400 W output to run high-demand appliances and equipment

Found A Better Price?

Share it with us now and we will beat it. Get the best deal online, guaranteed!

Live Chat With an Expert

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Order within

to get it by the earliest date.

Authorized SunGoldPower Dealer

Free & Fast Shipping From US Warehouses

Easy 30-Day Returns & Price Beat Guarantee

Lifetime Expert Support

Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter + PowerMax 51.2V 314AH Outdoor Energy Storage Battery

The Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter + PowerMax 51.2V 314AH Outdoor Energy Storage Battery is a complete whole-home energy solution designed for reliable backup power, efficient solar integration, and long-lasting energy storage. Featuring a powerful 11.4kW split-phase inverter with 200A whole-home backup capability and up to 16 parallel batteries (16.07kWh each), this system ensures dependable performance for both off-grid and grid-tied applications. With advanced safety certifications including UL1973 & UL9540A, IP65 outdoor protection, and intelligent monitoring via wireless and app integration, this package is engineered for durability, safety, and ease of use.

Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter + PowerMax 51.2V 314AH Outdoor Energy Storage Battery Features

High-Capacity Inverter (11.4kW) – Provides robust split-phase AC power with 200A passthrough, ensuring seamless whole-home backup.

Whole-Home Backup Ready – Supports critical loads and entire home circuits with 120/240V split phase output and rapid transfer time (<10ms).

Expandable Energy Storage – Includes the PowerMax 51.2V 314Ah LiFePO4 battery with 16.07kWh capacity, expandable from 1 to 16 units in parallel.

Smart Energy Management – Wireless monitoring via app and LCD display for real-time system control and energy insights.

Durable Outdoor Design – IP65/NEMA 3R rated inverter and rugged outdoor-rated PowerMax battery design.

Certified Safety – UL1973, UL9540A, UL1741, IEEE1547 certifications for compliance, reliability, and safe operation.

Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter + PowerMax 51.2V 314AH Outdoor Energy Storage Battery Applications

Whole-home backup – Keep your home running during outages with powerful inverter and scalable storage support.
Off-grid living – Reliable solution for remote homes, cabins, and farms.
Solar integration – Pair with solar PV systems for maximum energy independence.
Commercial backup – Provides dependable power for businesses or offices.
Emergency preparedness – Long-term storage ensures peace of mind during grid failures.

What's Included

Everything you need is included with your product.

1 x Sungold Power 11.4kW 48V Split Phase Hybrid Solar Inverter
1 x Mounting Bracket
1 x File Package
1 x Meter (Optinal)
2 x 300 A CT
4 x M6 Expansion Screw
1 x M6 Security Screw
1 x Wi-Fi / LAN Module
1 x Parallel Cable
1 x 9-Pin Terminal
4 x 4-Pin Terminal
2 x Toroid

1 x Sungold Power PowerMax 51.2V 314Ah Outdoor LiFePO4 Battery
3 × Mounting Frames (580 × 85.8 × 30mm)
1 × Mounting Frame Connecting Strip (375 × 39 × 12mm)
6 × Screws (M4 × 10)
12 × Mounting Frame Screws (M8 × 60 expansion bolts)
2 × Side Fasteners (80 × 40 × 36mm)
4 × Screws (M5 × 12)
2 × Power Cables (1.5m)
1 × Signal Cable (RJ45, 1.5m)
1 × RJ45 Waterproof Connector (M25 × 37mm)
1 × Grounding Wire (1.5mm)

Warranty

Inverter Warranty – 10 Years
Battery Warranty – 10 Years

SunGold Power 11.4kW 48V Split Phase Hybrid Solar Inverter | Whole Home Backup

Input (PV)

Category	Specification
Max. PV Input Power	15,000W
Max. PV Voltage	600V
Start-up Voltage	90V
MPPT Operating Voltage Range	70V – 540V
Max. Input Current per MPPT	30A / 22A / 22A
No. of MPPT	3

Input/Output (Battery)

Category	Specification
Compatible Battery Type	Lithium-ion / Lead-acid
Battery Voltage Range	40 V – 64 V
Max. Charge/Discharge Current	210 A / 210 A
Max. Charge/Discharge Power	10,000 W / 10,000 W

Output (Grid)

Category	Specification
Max. AC Output Power (PF=1)	11,400 W
Max. AC Output Current	47.5 A
Max. Grid Passthrough Current	200 A
Nominal Grid Voltage	120/240 V (Split phase) / 208 V (2/3 phase) V AC
Nominal Grid Frequency	50/60 Hz
Power Factor	>0.99 @ rated power (Adjustable 0.8LD ~ 0.8LG)

Output (Back Up)

Category	Specification
Max. AC Output Power (PF=1)	11,400 W
Nominal Output Current	41.7 A
Peak Power	20,000 VA
Nominal Output Voltage	120/240 V (Split phase) / 208 V (2/3 phase) V AC
Nominal Output Frequency	50 Hz / 60 Hz
Transfer Time	<10 ms (typical)
THDV	<3% @ 100% R Load

Protection

Category	Specification
Protection Categoryput Power (PF=1)	Class I
AC Overcurrent Protection	Yes
DC/AC Overvoltage Protection	DC Type II, AC Type III
AC Short Circuit Protection	Yes
DC Reverse Protection	Yes
Surge Arrester	DC Type II, AC Type III
RSD	Yes

General

Category	Specification
Ingress Protection Degree	IP65 / NEMA 3R
Operating Temperature Range	-25°C ~ 60°C (<45°C derating)
Dimensions (W×H×D)	17.6 × 35.5 × 10.6 in (448 × 901 × 270 mm)
Weight	103.6 lbs / 40 kg

HMI & COM

Category	Specification
Display	Wireless & APP + LED + LCD (Optional)
Communication Interface	CAN (for BMS), RS485 (for meter), RS485, CAN (for parallel), Optional: WiFi / LAN

SunGold Power 10KW 48V Split Phase Solar Inverter Specifications

Category	Specification
Product Model	PowerMax 314 Outdoor
Battery Type	LiFePO₄ (Lithium Iron Phosphate)
Rated Voltage	51.2 V
Rated Capacity	314 Ah
Rated Energy	16.07 kWh
Max Continuous Current	Charge: 190 A, Discharge: 190 A
Max Charging Voltage	57.6 V
Over Discharge Voltage	44.8 V
Peak Charging Current	220 A (3S)
Dimension (H×W×D)	41.3 × 18.1 × 10.7 in
Weight	271.2 lbs
Max Parallel Number	Up to 16 pcs

Frequently-Asked Questions

Can I start with one battery and add more later?

Yes, the system supports 1 to 16 PowerMax batteries in parallel, allowing you to expand capacity as your energy needs grow.

How much backup time can one battery provide?

Backup duration depends on load. Each 16.07kWh battery can support basic home essentials for several hours, expandable with additional batteries for longer runtimes.

Can the system power an entire home?

Yes, the 11.4kW inverter with 200A passthrough is designed for whole-home backup, supporting large appliances, HVAC systems, and essential circuits.

What’s the lifespan of the battery?

The LiFePO4 cells are rated for over 6,000 cycles, which typically translates to 10–15 years of reliable use depending on charging habits.

Is the system safe to install outdoors?

Yes, the PowerMax battery is outdoor-rated and built with IP-rated protection. The inverter is designed with IP65/NEMA 3R protection, ensuring safe operation in various weather conditions.

Can the system be monitored remotely?

Yes, it comes with Wi-Fi/LAN monitoring and a mobile app for real-time performance tracking, energy flow monitoring, and system diagnostics.

What’s the warranty coverage?

The inverter includes a 10-year warranty, and the PowerMax battery includes manufacturer coverage as detailed in its warranty policy.
