Victron Energy SmartSolar MPPT 250/70-Tr Solar Charge Controller

The Victron Energy SmartSolar MPPT 250/70-Tr is a high-performance solar charge controller designed to maximize energy harvest from large photovoltaic arrays while efficiently charging 12V, 24V, 36V, and 48V battery banks. Featuring Victron's ultra-fast Maximum Power Point Tracking (MPPT) technology, integrated Bluetooth connectivity, and compatibility with Victron's extensive monitoring ecosystem, the 250/70-Tr is ideal for off-grid, backup power, marine, RV, and commercial solar applications. Its advanced charging algorithms improve battery health and longevity while delivering exceptional conversion efficiency, even during rapidly changing weather conditions

Victron Energy SmartSolar MPPT 250/70-Tr Features

Ultra-Fast MPPT Technology - Tracks the optimum power point of the solar array with exceptional speed, improving energy harvest by up to 30% compared to PWM controllers and significantly outperforming slower MPPT controllers during variable weather conditions.
Integrated Bluetooth Smart - Built-in Bluetooth allows wireless monitoring, configuration, firmware updates, and historical performance tracking directly through the free VictronConnect app.
Supports High PV Voltage Arrays - Accepts up to 250V DC PV open-circuit voltage, enabling longer series strings and reducing wiring costs on larger solar installations.
Advanced Battery Charging - Fully programmable multi-stage charging profiles support lead-acid, AGM, Gel, lithium, and custom battery configurations for optimal charging performance.
Remote Monitoring with VRM - Compatible with Victron GX devices and the Victron Remote Management (VRM) portal for advanced remote monitoring and system management.
Intelligent Thermal Management - Automatically adjusts output power under high-temperature conditions to protect internal components while maintaining system reliability.
Programmable Relay - Integrated relay output can be configured for alarms, generator start/stop functions, battery monitoring, and other automation tasks.
VE.Direct Communication Port - Provides seamless integration with Victron GX devices, monitoring systems, displays, and other ecosystem components.

Victron Energy SmartSolar MPPT 250/70-Tr Applications

Off-grid solar power systems – Ideal for cabins, remote homes, and independent energy installations.
Residential battery storage – Maximizes solar harvesting for home energy systems.
RV and motorhome installations – Efficient charging for large mobile solar arrays.
Marine power systems – Reliable charging for yachts, sailboats, and commercial vessels.
Telecommunications sites – Supports critical infrastructure in remote locations.
Agricultural solar systems – Powers pumps, monitoring equipment, and farm operations.
Backup power installations – Integrates with battery storage for energy resilience.
Commercial solar projects – Suitable for larger PV arrays requiring high-voltage input capability.

What's Included?

Victron Energy SmartSolar MPPT 250/70-Tr Charge Controller
User Manual

Victron Energy SmartSolar MPPT 250/70-Tr Specifications

Electrical Specifications

Specification	Details
Battery Voltage	12 / 24 / 48 V Auto Select (software tool needed to select 36 V)
Rated Charge Current	70 A
Nominal PV Power, 12 V	1000 W
Nominal PV Power, 24 V	2000 W
Nominal PV Power, 36 V	3000 W
Nominal PV Power, 48 V	4000 W
Max. PV Short Circuit Current	35 A (max 30 A per MC4 connector)
Maximum PV Open Circuit Voltage	250 V absolute maximum coldest conditions; 245 V start-up and operating maximum
Maximum Efficiency	99%
Self-Consumption	Less than 35 mA @ 12 V / 20 mA @ 48 V
Charge Voltage "Absorption"	Default setting: 14.4 / 28.8 / 43.2 / 57.6 V (adjustable with: rotary switch, display, VE.Direct or Bluetooth)
Charge Voltage "Float"	Default setting: 13.8 / 27.6 / 41.4 / 55.2 V (adjustable: rotary switch, display, VE.Direct or Bluetooth)
Charge Voltage "Equalization"	Default setting: 16.2 V / 32.4 V / 48.6 V / 64.8 V (adjustable)
Charge Algorithm	Multi-stage adaptive (eight pre-programmed algorithms) or user defined algorithm
Temperature Compensation	-16 mV / -32 mV / -64 mV / °C
Protection	PV reverse polarity / Output short circuit / Over temperature
Operating Temperature	-30 to +60 °C (full rated output up to 40 °C)
Humidity	95%, non-condensing
Maximum Altitude	5000 m (full rated output up to 2000 m)
Environmental Condition	Indoor, unconditioned
Pollution Degree	PD3
Data Communication Port	VE.Direct or Bluetooth
Remote On/Off	Yes (2 pole connector)
Programmable Relay	DPST – AC rating: 240 VAC / 4 A; DC rating: 4 A up to 35 VDC, 1 A up to 60 VDC
Parallel Operation	Yes: up to 10 units can be synchronized with Bluetooth

Enclosure

Specification	Details
Colour	Blue (RAL 5012)
PV Terminals	35 mm² / AWG2 (Tr models); Two pairs of MC4 connectors (MC4 models)
Battery Terminals	35 mm² / AWG2
Protection Category	IP43 (electronic components), IP22 (connection area)
Weight	3 kg
Dimensions (h × w × d)	Tr models: 185 × 250 × 95 mm; MC4 models: 215 × 250 × 95 mm

Standards

Specification	Details
Safety	EN/IEC 62109-1, UL 1741, CSA C22.2

Stored Trends

Specification	Details
Data Stored	Battery voltage, current and temperature, as well as load output current, PV voltage and PV current
Number of Days Trends Data is Stored	46

Frequently Asked Questions

What does MPPT mean?

MPPT stands for Maximum Power Point Tracking. It is a technology that continuously adjusts operating conditions to extract the maximum available power from solar panels.

Can this controller charge lithium batteries?

Yes. The SmartSolar MPPT 250/70-Tr supports lithium batteries and offers customizable charging parameters through the VictronConnect app.

Does the controller include Bluetooth?

Yes. Bluetooth Smart is built directly into the controller, allowing wireless monitoring and configuration without additional accessories.

Can I monitor the system remotely?

Yes. When connected to a Victron GX device, the controller can be monitored remotely through the Victron Remote Management (VRM) Portal.

What battery voltages are supported?

The controller automatically detects and supports 12V, 24V, 36V, and 48V battery banks.

Is this controller suitable for large solar arrays?

Yes. With a maximum PV input voltage of 250V and 70A charging capability, it is designed for medium to large off-grid and energy storage systems.

Does it provide battery temperature compensation?

Yes. Battery temperature compensation is supported when used with a compatible temperature sensor.

Can multiple controllers be used in the same system?

Yes. Multiple SmartSolar controllers can operate together on the same battery bank for larger solar installations.

Manual

Victron Energy SmartSolar MPPT 250/70-Tr Datasheet
