Victron Energy Phoenix Inverter 12/3000 120VAC (Model: PIN123020100)
Power You Can Rely On — Even From a 12V Battery
The Victron Phoenix 12/3000 VE.Bus Inverter (Model PIN123020100) delivers robust, high-efficiency power conversion from a 12V battery source to 120V AC output. Ideal for off-grid, mobile, and backup power setups, this inverter is engineered with Victron's signature reliability and performance in mind. With a 3000W power rating, it's capable of supporting a wide range of household and commercial devices.
Key Features
-
3000W Continuous Power Output
Ideal for running appliances, electronics, and tools with ease.
-
Pure Sine Wave Output
Provides clean and stable AC power—safe for sensitive devices like laptops, TVs, and medical equipment.
-
VE.Bus Communication Interface
Supports advanced system integration, parallel and three-phase operation, and remote monitoring via GX devices.
-
High Efficiency Conversion
Optimizes battery usage, reducing energy loss and extending runtime.
-
Advanced Safety Protections
Includes built-in protection against overloads, short circuits, high temperature, and low battery voltage.
-
Compact, Rugged Design
Easy to install in homes, vehicles, boats, or industrial setups.
Technology Overview
The Phoenix 12/3000 features Victron’s proven inverter technology, offering reliable performance even under demanding conditions. Its VE.Bus communication port enables integration with Victron’s monitoring ecosystem, including VictronConnect, Color Control GX, Cerbo GX, and the VRM Portal.
Installation & Compatibility
Designed for flexibility, the Phoenix 12/3000 can be mounted in a variety of configurations and integrates seamlessly with:
-
12V battery banks (AGM, GEL, Lithium, Lead Carbon)
-
SmartSolar MPPT charge controllers
-
BMV or SmartShunt battery monitors
-
Victron Energy storage systems
Applications
-
Off-grid homes and cabins
-
RVs, vans, and tiny homes
-
Boats and marine systems
-
Solar energy backup power systems
-
Remote industrial and telecom equipment
Technical Specifications
Specification |
Value |
Model Number |
PIN123020100 |
Power Output |
3000W (Continuous) |
Input Voltage |
12V DC |
Output Voltage |
120V AC ±2% |
Waveform |
Pure Sine Wave |
Frequency |
60Hz ±0.1% |
Peak Power |
~6000W |
Efficiency |
Up to ~92% |
Communication |
VE.Bus |
Monitoring Ready |
Yes – GX devices & VRM compatible |
Dimensions |
362 x 258 x 218 mm (14.3 x 10.2 x 8.6 in) |
Weight |
~18 kg (39.7 lbs) |
