Victron Energy SCC110020160R SmartSolar MPPT 100/20 Solar Charge Controller

Elevate your solar system’s efficiency with the Victron Energy SCC110020160R, a top-tier SmartSolar MPPT 100/20 charge controller. Designed for 12V, 24V, or 48V battery configurations, this advanced MPPT controller maximizes solar energy collection, ensuring faster and more efficient battery charging. Whether for off-grid systems, RVs, or marine applications, it’s built to optimize your energy harvest for maximum performance and cost-effectiveness.

Key Features:

  • Advanced MPPT Technology: Delivers up to 30% more energy compared to traditional PWM chargers by tracking the maximum power point of your solar panels, even in fluctuating light conditions.
  • Automatic Battery Voltage Detection: The controller automatically detects and adjusts to 12V, 24V, or 48V battery systems, offering hassle-free installation and flexible use.
  • Bluetooth Connectivity: Built-in Bluetooth for easy monitoring and control through the VictronConnect app, allowing you to adjust settings and track performance on your smartphone or tablet.
  • Integrated Temperature Sensor: Optimizes charging performance across varying environmental conditions to enhance system reliability.
  • High Efficiency: Up to 98% efficiency, ensuring minimal energy loss and maximizing the output of your solar system.

Specifications:

  • Max PV Input Voltage: 100V
  • Max Charge Current: 20A
  • Max PV Power:
    • 12V System: 290W
    • 24V System: 580W
    • 48V System: 1160W
  • Absorption Charge Voltage: 14.4V / 28.8V / 57.6V (adjustable)
  • Float Charge Voltage: 13.8V / 27.6V / 55.2V (adjustable)
  • Operating Temperature Range: -30°C to +60°C
  • Communication: Bluetooth for VictronConnect app
  • Protection Features: Overload, Short Circuit, High Temperature, Reverse Polarity

Applications:

The SCC110020160R is ideal for:

  • Off-Grid Solar Systems: Perfect for powering remote cabins, RVs, boats, and more.
  • Residential and Commercial Installations: Optimizes energy efficiency for battery storage systems in both small and large-scale projects.
  • Energy Independence: Provides reliable and cost-effective energy solutions while reducing reliance on the grid.

Specifications:

Specification Value
Max PV Input Voltage 100V
Max Charge Current 20A
Max PV Power (12V/24V system) 290W / 580W
Charge Voltage Absorption 14.4V / 28.8V (adjustable)
Charge Voltage Float 13.8V / 27.6V (adjustable)
Operating Temperature Range -30°C to +60°C
Communication Bluetooth for VictronConnect App
Protection Features Overload, Short Circuit, High Temperature, Reverse Polarity
