Victron Energy 50 Amp MPPT 12/24 VDC 100 VOC (SmartSolar) Solar Charge Controller

The Victron Energy SmartSolar MPPT 100/50 is a compact, high-efficiency solar charge controller designed to maximize energy harvest from photovoltaic systems while providing intelligent battery charging for 12V and 24V battery banks. Featuring Victron's advanced Maximum Power Point Tracking (MPPT) technology, built-in Bluetooth connectivity, and compatibility with the VictronConnect app, the SmartSolar MPPT 100/50 delivers superior charging performance, real-time monitoring, and simplified system management. Its robust design makes it ideal for RVs, marine applications, off-grid cabins, backup power systems, and residential solar installations.

Victron Energy 50 Amp MPPT 12/24 VDC 100 VOC (SmartSolar) Solar Charge Controller Features

Ultra-Fast MPPT Technology - Maximizes solar energy production. Continuously tracks the optimal operating point of solar panels, increasing energy harvest compared to traditional PWM controllers.

Built-In Bluetooth Smart - Wireless monitoring and control. Connect directly through the VictronConnect app to configure settings, monitor charging performance, and update firmware.

50 Amp Charging Capacity - Ideal for medium-sized solar systems. Supports charging currents up to 50A for residential, marine, RV, and backup power applications.

100V PV Input Capability - Flexible solar array design. Supports higher-voltage panel configurations to reduce wiring losses and installation costs.

Adaptive Multi-Stage Charging - Extends battery life. Automatically adjusts charging stages based on battery condition and usage patterns.

High Conversion Efficiency - Up to 98% efficiency. Converts more solar energy into usable battery power with minimal losses.

VE.Direct Communication - Easy system integration. Connects with Victron GX devices, displays, and monitoring equipment for advanced energy management.

Comprehensive Protection - Reliable operation. Includes PV reverse polarity, output short circuit, and over-temperature protection.

Victron Energy 50 Amp MPPT 12/24 VDC 100 VOC (SmartSolar) Solar Charge Controller Applications

RV solar systems – Efficient charging for recreational vehicles and campers.
Marine installations – Reliable battery charging for boats and yachts.
Off-grid cabins – Maintains battery banks in remote locations.
Backup power systems – Supports battery storage for emergency power applications.
Tiny homes – Ideal for compact renewable energy systems.
Remote monitoring stations – Provides dependable solar charging for equipment.
Residential solar systems – Optimizes battery charging in small to medium installations.
Agricultural applications – Powers fencing, monitoring systems, and remote equipment.

What's Included?

Victron Energy 50 Amp MPPT 12/24 VDC 100 VOC (Smart Solar), Solar Charge Controller
User Manual

Victron Energy 50 Amp MPPT 12/24 VDC 100 VOC (SmartSolar) Solar Charge Controller Specifications

Electrical Specifications

Specification	Details
Battery Voltage	12/24 V Auto Select
Rated Charge Current	50 A
Nominal PV Power, 12 V	700 W
Nominal PV Power, 24 V	1400 W
Maximum PV Open Circuit Voltage	100 V
Max. PV Short Circuit Current	60 A
Maximum Efficiency	98%
Self-Consumption	12 V: 30 mA 24 V: 20 mA
Charge Voltage "Absorption"	Default setting: 14.4 V / 28.8 V (adjustable)
Charge Voltage "Float"	Default setting: 13.8 V / 27.6 V (adjustable)
Charge Algorithm	Multi-stage adaptive
Temperature Compensation	-16 mV / °C resp. -32 mV / °C
Protection	PV reverse polarity Output short circuit Over temperature
Operating Temperature	-30 to +60 °C (full rated output up to 40 °C)
Humidity	95%, non-condensing
Data Communication Port	VE.Direct

Enclosure

Specification	Details
Colour	Blue (RAL 5012)
Power Terminals	16 mm² / AWG6
Protection Category	IP43 (electronic components), IP22 (connection area)
Weight	1.3 kg
Dimensions (h × w × d)	130 × 186 × 70 mm

Standards

Specification	Details
Safety	EN/IEC 62109-1, UL 1741, CSA C22.2

Stored Trends

Specification	Details
Data Stored	Battery voltage, current and temperature, as well as load output current, PV voltage and PV current
Number of Days Trends Data is Stored	46

Frequently Asked Questions

What is MPPT technology?

MPPT (Maximum Power Point Tracking) continuously adjusts the operating point of solar panels to extract the maximum available power and improve charging efficiency.

Does the SmartSolar MPPT 100/50 include Bluetooth?

Yes. Built-in Bluetooth allows wireless monitoring, configuration, diagnostics, and firmware updates through the VictronConnect app.

What battery voltages are supported?

The controller automatically detects and supports both 12V and 24V battery banks.

Can I use lithium batteries with this controller?

Yes. The SmartSolar MPPT 100/50 supports lithium batteries and can be configured for custom charging profiles.

What is the maximum solar panel input voltage?

The controller supports a maximum PV open-circuit voltage of 100V.

Can I monitor the controller remotely?

Yes. Through the VE.Direct port, the controller can connect to compatible Victron GX devices for remote monitoring via the Victron Remote Management (VRM) platform.

What protections are built into the controller?

The controller includes protection against PV reverse polarity, output short circuits, and over-temperature conditions.

Is this suitable for RV and marine applications?

Yes. Its compact size, Bluetooth connectivity, and high charging efficiency make it a popular choice for RV, van, and marine solar systems.
