Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus

Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus

BY: Victron Energy | SKU: PMP245021010 Availability: In Stock
$2,087.60

Notify me when back in stock

Found a Better Price?

Share it with us now and we will beat it. Get the best deal online - Guaranteed!

Call/Text Us: 877-556-3347
Live Chat With an Expert

  • Authorized Victron Energy Dealer

    Full manufacturer warranty included

  • Free Shipping + No Sales Tax (Most States)

    More savings on every purchase

  • Easy 30-Day Returns & Price Beat Guarantee

    Risk-free shopping + best price guaranteed

  • Lifetime Expert Support

    Dedicated help whenever you need it

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus

The Victron Energy MultiPlus 24/5000/120-100 is a powerful 24V inverter/charger built for larger off-grid, marine, RV, and backup systems. It combines a 5000VA pure sine wave inverter, a high-output 120A adaptive battery charger, and a fast 100A transfer switch in one unit. When shore or generator power is present, it passes AC through while charging your battery bank. When AC drops out, it switches to inverter power automatically to keep your loads running smoothly. With PowerControl and PowerAssist, it can manage limited AC sources while still supporting heavy surge loads when needed.

Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus Features

5000VA pure sine wave inverter – Clean, stable 230V AC output that’s safe for sensitive electronics and appliances.

High surge capability – Handles demanding startup loads with up to 10,000W peak power.

120A adaptive battery charger – Fast multi-stage charging for large 24V battery banks.

100A transfer switch – Automatic switching between shore/generator input and inverter output.

PowerControl – Limits AC draw to prevent tripping weak shore or generator circuits.

PowerAssist – Adds battery power during short load spikes to support heavier demands.

VE.Bus communication – Enables monitoring, remote control, and parallel or three-phase system expansion.

Programmable relay – Lets you configure alarms, generator auto-start, or custom system triggers.

Rugged aluminum enclosure – Durable housing made for mobile and stationary installations.

Placeholder Image

Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus Applications

  • Off-grid home or cabin – high-capacity inverter/charger for reliable daily power.
  • RV or van builds – supports large 24V mobile systems with strong AC output.
  • Marine electrical systems – stable onboard AC with shore pass-through charging.
  • Whole-home backup – keeps essential circuits running through outages.
  • Hybrid generator systems – balances limited generator power with battery assist.

What's Included

Everything you need is included with your product.

  • Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus
  • User Manual

Warranty

  • 5-year Victron warranty

Victron Energy MultiPlus 24/5000/120-100 230V VE.Bus Specifications

Specification Details
Nominal Battery voltage 24 V battery | 48 V battery
PowerControl Yes
PowerAssist Yes
AC input Input voltage range: 187 -250 V | Input frequency: 50/60 Hz | Cos Φ >0.8
Transfer switch (A) 100

Inverter

Specification Details
Input voltage range (VDC) 9,5 – 17V | 19 – 33V | 38– 66V
Input current (A DC) 238 / 118
Output Output voltage: 230 VAC ± 2 % | Frequency: 50 Hz ± 0,1 %
Cont. output power at 25 °C (VA) 4000 VA
Cont. output power at 25 °C (W) 4000w
Cont. output power at 40 °C (W) 3700w
Cont. output power at 65 °C (W) 3000w
Peak power (W) 10.000w
Maximum continuous Output current (A~) 19
Power factor range ±0.8
Maximum output fault current 53A peak 1sec
Maximum efficiency (%) 94 / 95
Zero load power (W) 30 / 35
Zero load power in AES mode (W) 25 / 30
Zero load power in Search mode (W) 10 / 15

Charger

Specification Details
AC Input Input voltage range: 187 -265 VAC | Input frequency: 45 – 65 Hz | Power factor: 1
Charge voltage 'absorption' (VDC) 14,4 / 28,8 / 57,6
Charge voltage 'float' (VDC) 13,8 / 27,6 / 55,2
Storage mode (VDC) 13,2 / 26,4 / 52,8
Charge current house battery (A) 120 / 70
Charge current starter battery (A) 4 (12 V and 24 V models only)
Battery temperature sensor Yes

General

Specification Details
Auxiliary output Yes (50A)
Programmable relay Yes
Protection a - g
VE.Bus communication port For parallel and three phase operation, remote monitoring and system integration
General purpose com. port Yes
Remote on-off Yes
Common Characteristics Operating temp. range: -40 to +65 °C (fan assisted cooling) | Humidity (non -condensing): max 95 %
Maximum altitude 2000 m.

Enclosure

Specification Details
Common Characteristics Material & Colour: aluminium (blue RAL 5012), Protection category: IP20, pollution degree 2, OVC III Icw: 6kA 30mS
Battery-connection Four M8 bolts (2 plus and 2 minus connections)
230V AC-connection M6 bolts
Weight 30 kg
Dimensions (hxwxd in mm) 444 x 328 x 240

Standards

Specification Details
Safety EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1
Emission / Immunity EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Road vehicles 12 V and 24 V models: ECE R10-4

Frequently-Asked Questions

What size system is this best for?

This model is best for larger 24V systems needing high continuous AC output (5000VA) and fast charging (120A), such as off-grid homes, big RV builds, or marine systems.

Can it start heavy appliances?

Yes. With up to 10,000W peak power, it supports high startup surges from pumps, compressors, power tools, and similar loads.

Will it work with limited generator or shore power?

Yes. PowerControl keeps AC draw within your input limit, and PowerAssist boosts short spikes using battery power.

Can I expand to parallel or three-phase later?

Yes. VE.Bus allows parallel stacking and three-phase configurations with compatible Victron units.
