Victron Energy MultiPlus-II 24/3000/70-32 230V GX

Victron Energy MultiPlus-II 24/3000/70-32 230V GX

BY: Victron Energy | SKU: PMP242306000 Availability: In Stock
$1,007.25

Notify me when back in stock

Found a Better Price?

Share it with us now and we will beat it. Get the best deal online - Guaranteed!

Call/Text Us: 877-556-3347
Live Chat With an Expert

  • Authorized Victron Energy Dealer

    Full manufacturer warranty included

  • Free Shipping + No Sales Tax (Most States)

    More savings on every purchase

  • Easy 30-Day Returns & Price Beat Guarantee

    Risk-free shopping + best price guaranteed

  • Lifetime Expert Support

    Dedicated help whenever you need it

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Victron Energy MultiPlus-II 24/3000/70-32 230V GX

The Victron Energy MultiPlus-II GX 24/3000/70-32 is a smart all-in-one inverter/charger with a built-in GX communication hub, designed for advanced 24V off-grid, RV, marine, and backup systems. It delivers clean pure sine wave AC power, fast adaptive charging, and seamless transfer between shore/generator and battery power. With the integrated GX interface, you get system monitoring and connectivity in one unit—reducing extra hardware and simplifying installs. PowerControl and PowerAssist help prevent overload on limited AC sources while still supporting high inrush loads from appliances and tools.

Victron Energy MultiPlus-II 24/3000/70-32 230V GX Features

Built-in GX monitoring hub – Integrated communication center lets you monitor, configure, and manage the system without needing a separate GX device.

3000VA pure sine wave inverter – Provides stable 230V AC output safe for sensitive electronics and household appliances.

High surge power – Supports demanding startup loads with up to 5500W peak power.

70A adaptive battery charger – Multi-stage charging optimized for 24V LiFePO4 and lead-acid banks.

32A transfer switch – Automatically switches between AC input and inverter output with no interruption to loads.

PowerControl – Limits AC draw to protect weak shore or generator circuits from overload.

PowerAssist – Adds battery power during short spikes to prevent breaker trips and voltage drop.

VE.Bus integration – Enables parallel/three-phase setups and full Victron ecosystem compatibility.

Multiple interfaces – Built-in VE.Can, USB, Ethernet, VE.Direct, and Wi-Fi for flexible connectivity.

Programmable relay and I/O – Supports alarms, generator auto-start, or custom automation.

Placeholder Image

Victron Energy MultiPlus-II 24/3000/70-32 230V GX Applications

  • Off-grid solar systems – central inverter/charger with built-in monitoring for cabins and remote homes.
  • RV and van builds (24V) – strong AC output and fast charging for full-time mobile power.
  • Marine electrical systems – stable onboard AC with shore pass-through and smart monitoring.
  • Backup power setups – keeps essential circuits running through outages.
  • Hybrid generator systems – balances limited generator power and battery assist automatically.
Placeholder Image

What's Included

Everything you need is included with your product.

  • Victron Energy MultiPlus-II 24/3000/70-32 230V GX
  • User Manual

Warranty

  • 5-year Victron warranty

Victron Energy MultiPlus-II 24/3000/70-32 230V GX Specifications

Specification Details
PowerControl & PowerAssist Yes
Transfer switch 32A
Maximum AC input current 32A
Auxiliary output Yes (32A)

Inverter

Specification Details
Input voltage range 19 - 33 V
Output in inverter mode Output voltage: 230 VAC ± 2% | Frequency: 50 Hz ± 0,1%
Cont. output power at 25°C (VA) 3000VA
Cont. output power at 25°C 2400W
Cont. output power at 40 2200W
Cont. output power at 65°C 1700W
Maximum feed-in power 3000VA
Peak power 5500W
Maximum efficiency 94%
Zero load power 13W
Zero load power in AES mode 9W
Zero load power in Search mode 3W

Charger

Specification Details
AC Input Input voltage range: 187-265 VAC | Input frequency: 45 – 65 Hz
Charge voltage 'absorption' 28.8V
Charge voltage 'float' 27.6V6 / 55,2V
Storage mode 26.4V
Max. battery charge current 70A
Battery temperature sensor Yes

General

Specification Details
Programmable (AUX) relay Yes
Auxiliary power supply 12V / 100mA
Programmable open collector output 70V / 100mA
Analog-digital aux inputs Yes, 2x
Temperature sensor Yes
Voltage sense contacts Yes
Protection a - g
VE.Bus communication port For parallel and three-phase operation, remote monitoring and system integration
General purpose communication port Yes, 2x
Interfaces VE.Can, USB, Ethernet, VE.Direct, Wi-Fi
External AC current sensor (optional 50A
Remote on-off Yes
Operating temperature range -40 to +65 °C (fan-assisted cooling). Maximum Altitude 2000m
Humidity (non-condensing) max 95%

Enclosure

Specification Details
Material & Colour Steel, blue RAL 5012
Protection category IP22
Battery-connection M8 bolts
230 VAC-connection Screw terminals 13 mm ² (6 AWG)
Weight kg 20kg
Dimensions (hxwxd) mm 506 x 275 x 147 mm

Standards

Specification Details
Safety EN-IEC 62019-1, EN-IEC 6201-2, EN-IEC 60335-1, EN-IEC 60335-2-29
Emission / Immunity EN55014-1, EN 55014-2 EN-IEC 61000-3-2, EN-IEC 61000-3-3 IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Uninterruptible power supply IEC 62040-1

Frequently-Asked Questions

What does the “GX” version add compared to a standard MultiPlus-II?

The GX version includes a built-in monitoring and communication hub, letting you manage the system without needing an external GX device.

Can this run heavy appliances?

Yes. It provides 3000VA continuous power and up to 5500W peak for startup surges.

Is it suitable for lithium batteries?

Yes. The adaptive charger supports LiFePO4 and other 24V battery types when configured correctly.

Can it work with limited shore or generator power?

Yes. PowerControl limits charging draw, and PowerAssist adds battery boost during short spikes.
