Victron Lithium-Iron-Phosphate (LiFePO4 or LFP) Smart Battery, 12.8V/200Ah

Victron Lithium-Iron-Phosphate (LiFePO4 or LFP) Smart Battery, 12.8V/200Ah

Name: Victron Lithium-Iron-Phosphate (LiFePO4 or LFP) Smart Battery, 12.8V/200Ah
Brand: Victron Energy
SKU: BAT512120610
Price: 1500.0 USD
Availability: InStock

BY: Victron Energy

SKU: BAT512120610

| Availability: In stock

$1,745.00

$1,500.00

You Save: $245.00

Found A Better Price?

Share it with us now and we will beat it. Get the best deal online, guaranteed!

Live Chat With an Expert

Estimated Delivery Between

and .

Order within to get it by the earliest date.

Order within

to get it by the earliest date.

Authorized Victron Energy Dealer

Free & Fast Shipping From US Warehouses

Easy 30-Day Returns & Price Beat Guarantee

Lifetime Expert Support

Victron Lithium-Iron-Phosphate (LiFePO4 or LFP) Smart Battery, 12.8V/200Ah

The Victron LiFePO₄ Smart Battery 12.8V/200Ah (BAT512120610) is a premium, high-capacity lithium battery designed for demanding energy storage applications such as off-grid systems, marine power, RV setups, and industrial energy solutions. Using Lithium Iron Phosphate (LiFePO₄) chemistry, it delivers superior safety, long service life, and exceptional energy efficiency.

Engineered for longevity and performance, this Smart Battery offers 2,500 cycles at 80% depth of discharge and up to 5,000 cycles at 50% DoD, ensuring reliable, low-maintenance operation for years. Built-in Bluetooth connectivity allows users to monitor voltage, temperature, and alarms through the VictronConnect App, while compatibility with Victron’s external BMS ensures total system protection.

Dependable, efficient, and intelligently monitored — the Victron 12.8V/200Ah Smart Battery is built to power advanced off-grid and hybrid systems.

Victron Lithium-Iron-Phosphate (LiFePO₄) Smart Battery Features

Advanced LiFePO₄ Chemistry - Offers the safest and most stable lithium battery technology with long life, low internal resistance, and high power density.

Bluetooth Smart Monitoring - Monitor battery health, voltage, temperature, and alarms directly from the VictronConnect App via integrated Bluetooth.

High-Power Output - Delivers a maximum continuous discharge current of 400A, making it suitable for large inverters and demanding energy systems.

Outstanding Efficiency - Up to 92% round-trip efficiency, significantly outperforming lead-acid batteries (≈80%). Maintains efficiency even under shallow discharge conditions.

Long Cycle Life - Designed for durability with 2,500 cycles at 80% DoD and 5,000 cycles at 50% DoD, offering years of reliable operation.

Lightweight & Compact Design - Saves up to 70% in weight and space compared to traditional batteries, ideal for mobile, marine, and solar applications.

External BMS Compatibility - Requires a Victron external Battery Management System (BMS) for complete control of charging, discharging, and temperature protection.

Victron Lithium-Iron-Phosphate (LiFePO₄) Smart Battery Applications

Off-Grid Solar Systems – Reliable energy storage for residential or commercial setups.
Marine Power Systems – Efficient, deep-cycle energy source for onboard electronics and systems.
RVs & Camper Vans – Long-lasting power for off-grid travel and mobile living.
Industrial & Backup Power – Heavy-duty storage for critical systems and hybrid installations.
Mobile Workshops & Service Vehicles – Clean, efficient energy for on-the-go professionals.

What's Included

Everything you need is included with your product.

1 × Victron 12.8V 200Ah LiFePO₄ Smart Battery (BAT512120610)

User Manual

Warranty

Victron Energy Standard Warranty: 5 Years

Victron Lithium-Iron-Phosphate (LiFePO₄) Smart Battery Specifications

Category	Specifications
Battery Model (LFP-Smart)	LFPSmart 12,8/200
Nominal Voltage	12,8 V
Nominal Capacity @25°C	200 Ah
Nominal Capacity @0°C	160 Ah
Nominal Capacity @–20°C	100 Ah
Nominal Energy @25°C	2560 Wh
Capacity Loss	<1% per 100 cycles @25°C, 100% DoD
Energy Loss	<1% per 100 cycles @25°C, 100% DoD
Round Trip Efficiency	92%

Cycle Life (Capacity ≥ 80% of Nominal)

Category	Specifications
80% DoD	2500 cycles
70% DoD	3000 cycles
50% DoD	5000 cycles

Discharge

Category	Specifications
Max Continuous Discharge Current	400 A
Recommended Continuous Discharge Current	≤200 A
End of Discharge Voltage	11.2 V
Internal resistance	0.8 mΩ

Operating Conditions

Category	Specifications
Operating Temperature	Discharge: –20°C to +50°C / Charge: +5°C to +50°C
Storage Temperature	–45°C to +70°C
Humidity (Non-condensing)	Max. 95%
Protection Class	IP22

Charge

Category	Specifications
Charge Voltage	Between 14 V/28 V and 14,4 V/28,8 V (14,2 V/28,4 V recommended)
Float Voltage	13,5 V/27 V
Max Charge Current	400 A
Recommended Charge Current	≤100 A

Mounting

Category	Specifications
Can Be Placed on Their Sides	Yes

Other

Category	Specifications
Max Storage Time @25°C	1 year
BMS Connection	Male + female cable with M8 circular connector, length 50 cm
Max batteries per BMS	20 (102 kWh per BMS⁴)
Power connection (threaded inserts)	M8
Dimensions (hxwxd) mm	237 x 321 x 152
Weight	20 kg

Standards

Category	Specifications
Safety	Cells: UL1973 + IEC62619:2017 + UL9540A Battery: IEC62619:2017 + IEC62620:2014
	EN 60335-1:2012/AC:2014, EN-IEC 62368-1: 2020, IEC 61427-1:2013
EMC	EN-IEC 61000-6-3:2007/A1:2011/AC:2012 - EN 55014-1:2017/A11:2020
Automotive	ECE R10-6

Frequently-Asked Questions

Do I need an external BMS?

Yes. The Victron Smart Battery requires a Victron BMS for safe operation, ensuring balanced charging, temperature monitoring, and over-discharge protection.

Can this battery be monitored via Bluetooth?

Yes. The integrated Bluetooth module allows real-time monitoring of voltage, temperature, and alarm data through the VictronConnect App.

Is this battery suitable for off-grid solar?

Absolutely. Its high cycle life, energy density, and efficiency make it perfect for solar and hybrid systems.

How does it compare to the SuperPack model?

The Smart Battery requires an external BMS for greater flexibility, while the SuperPack has a built-in BMS for simpler plug-and-play setups.
